Refresh your ride with Alpine
Alpine’s been building quality car speakers for decades, and their latest S-Series speakers are no exception. If you’ve been living with anemic factory sound, this step up in range, tone definition, and power handling will make you giddy just about every time you hop behind the wheel. And if you’re really jonesing for a boost in sound quality, hook them up to a powerful aftermarket stereo or amp for increased performance.
Step up the highs
Move on from muddy highs with this pair of Alpine S-S10TW tweeters. With power handling up to 80 watts RMS, you can comfortably incorporate these silk dome tweeters into a high-powered system. Get ready to enjoy excellent detail at a hearty volume.
Sleek mounting
Alpine includes versatile hardware for mounting the tweeters in the best spot in your car and attaining a vibrant soundstage.
Installation note: You’ll need a pair of our universal backstraps to install these tweeters in the factory locations.
Product highlights:
- 1″ silk dome tweeters (pair)
- swivel flush-mount hardware included
- in-line passive crossovers
- handles up to 80 watts RMS (240 watts peak power)
- frequency response: 1,000-22,000 Hz
- impedance: 6 ohms
- sensitivity: 88 dB
- flush-mount depth: 3/4″
- cutout diameter: 2″
- warranty: 1 year
- MFR # S-S10TW
- Item # 500SS10TW
- California customers: Please click here for your Proposition 65 WARNING.
What’s in the box:
Alpine S-S10TW owner’s manual
If you need assistance accessing this owner’s manual, please give us a call.
- 2 Tweeters (each has a 30″ length of wire attached)
- 2 Flush mount housings (with tweeters installed)
- 2 Tweeter grilles (installed)
- Two 38″ Wires with in-line crossovers (each has quick slides on the output end and bare wire on the other)
- 2 Flush mount retention rings
- 2 Stealth brackets
- 2 Foam self-adhesive pads
- 2 Foam self-adhesive rings
- 2 Alpine logo badges
- 1 Logo placement bracket
- Warranty information
- On-line product registration information
- Important notice sheet
- Template and specs on box
Features & specs
| General | ||
|---|---|---|
| Speaker Size | 1 | |
| Driver Design | 1-way | |
| Woofer Design | — | |
| Woofer Material | — | |
| Woofer Surround | — | |
| Midrange Design | — | |
| Midrange Material | — | |
| Tweeter Design | Dome | |
| Tweeter Material | Silk | |
| Super Tweeter Design | — | |
| Super Tweeter Material | — | |
| Impedance (Ohms) | 6 | |
| Weather-resistant | No | |
| Grilles Included | Black steel mesh, Fixed | |
| Parts Warranty | 1 Year | |
| Labor Warranty | 1 Year | |
| Specifications | ||
| Sensitivity (1W at 1 meter) | 88 | |
| Sensitivity at 2.83 volts | N/A | |
| Frequency Response | 1000 – 22k Hz | |
| Maximum RMS Wattage | 80 | |
| Peak Power Handling (Watts) | 240 | |
| Top-mount Depth (Inches) | 0 11/16 | |
| Bottom-mount Depth (Inches) | 0 3/4 | |
| Cutout Diameter or Length (inches) | 2 1/16 | |
| Mounting Height (Inches) | 0.462 | |
| Frame Width | 2.297 | |
| Frame Length | 2.297 | |
- Alpine SPS-110TW
Product Research
Features
Tweeter Mounting Options: The tweeters can be flush mounted using the supplied flush mount brackets and rings. Once mounted, the tweeters can swivel approximately 15° for optimum imaging. The tweeters can also be mounted in factory tweeter locations behind factory tweeter grilles using the supplied stealth mounting brackets. (The stealth brackets have a multitude of tabs used for different mounting configurations. When not needed, the tabs can easily be removed. The factory location measurements in the chart below are generally minimums, with some tabs removed.)
| Flush Mount (swivel) | Factory Location (bottom mount) | Factory Location (top mount) | Surface Mount (under factory grille) | |
|---|---|---|---|---|
| Mounting Depth | 0.67″ | 0.714″ | 0.8″ | 0″ |
| Mounting Height | 0.462″ | 0″ | 0.058″ | 0.8″ |
| Cutout Diameter | 2.01″ | 1.723″ | 1.723″ | N/A |
| Frame Diameter | 2.297″ | 2.425″ | 2.425″ | 2.57″ |
Crossovers: The 12 dB/octave high-pass crossovers are in-line with the included 38″ speaker wires. The crossover section is approximately 4″ long and ⅝” wide.
