JL Audio 10W0v3-4 W0v3 Series 10″ 4-ohm subwoofer
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
$139.99
-
Pick up from the Woodmart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year
-
Free 30-Day returns
Payment Methods:
Description
Precision-built bass
The JL Audio name means high-quality sound, and the 10W0v3-4 10″ subwoofer doesn’t come up short when delivering trademark JL performance. You’ll find patented technologies like an optimized motor system that promotes precise, linear cone movement, plus advanced cooling systems throughout the frame for rapid heat dissipation.
Long-lasting performance
This W0v3 Series sub features a tough polypropylene cone that resists flexing, and a durable foam surround that’ll stand up to hard use. The cone’s extra-long excursion capability lets it hit truly deep notes without distorting, while the hefty 2-inch voice coil drives the woofer accurately for top-notch performance under extreme conditions.
The patented elevated frame design delivers air flow directly to the voice coil, cooling it for better power handling. JL Audio designed this sub to work in compact sealed or medium-sized ported enclosures, and they offer an optional grille that’ll protect your JL Audio sub in its box.
Product highlights:
- Featured in our article: Best 10″ car subwoofers for 2025
- 10″ 4-ohm subwoofer
- polypropylene cone with foam surround
- power range: 75-300 watts RMS
- peak power handling: 600 watts
- frequency response: 25-250 Hz
- sensitivity: 84.07 dB
- top-mount depth: 4-15/16″
- sealed box volume: 0.65 cubic feet
- ported box volume: 1.125 cubic feet
- grille not included
- warranty: 1 year
- MFR # 010-03039-00
- Item # 13610W0V34
- California customers: Please click here for your Proposition 65 WARNING.
What’s in the box:
JL Audio 10W0v3-4 owner’s manual
If you need assistance accessing this owner’s manual, please give us a call.
- One 10″ Single voice coil 4-ohm subwoofer
- Owner’s Manual
Features & specs
| Features and Specs | ||
|---|---|---|
| Size | 10-inch | |
| Impedance (Ohms) | 4 | |
| Cone Material | Polypropylene | |
| Surround Material | Foam | |
| Basket Material | Steel | |
| Grille | None included | |
| Free-Air | No | |
| Dual Voice Coil | No | |
| Sensitivity | 84.07 dB at 1 watt | |
| Frequency Response | 25 – 250 Hz | |
| Max RMS Power Handling | 300 | |
| Peak Power Handling (Watts) | 600 | |
| Top Mount Depth (inches) | 4 15/16 | |
| Bottom Mount Depth (inches) | N/A | |
| Cutout Diameter or Length (inches) | 8 13/16 | |
| Frame Width | 10.526 | |
| Frame Length | 10.526 | |
| Vas (liters) | 31.01 | |
| Fs (Hz) | 32.09 | |
| Qts | 0.604 | |
| Xmax (millimeters) | 11.4 | |
| Parts Warranty | 1 Year | |
| Labor Warranty | 1 Year | |
| Box Requirements | ||
| Ideal Sealed Box Volume (cubic feet) | 0.65 | |
| Minimum Sealed Box Volume (cubic feet) | N/A | |
| Maximum Sealed Box Volume (cubic feet) | N/A | |
| Ideal Ported Box Volume (cubic feet) | 1.125 | |
| Minimum Ported Box Volume (cubic feet) | 0.87 | |
| Maximum Ported Box Volume (cubic feet) | 1.35 | |
| Port diameter (inches) | N/A | |
| Port length (inches) | N/A | |
- JL Audio 10WXv2
- JL Audio 10W0v2-4
Product Research
Features
Enclosure Compatibility
Features
Dynamic Motor Analysis (DMA): DMA is JL Audio’s proprietary method aimed at improving dynamic motor behavior. As a result of DMA optimization, 10W0v3-4 motors display linear force over a long excursion range, and also maintain a stable fixed magnetic field in the gap over a wide power range. The result is reduced distortion, faithfully reproduced transients, and tight, clean, articulate bass.
Elevated Frame Cooling: The elevated frame design of the 10W0v3-4 delivers cool air through slots directly above the top plate to the voice coil. This not only enhances power handling, but also sound quality by minimizing dynamic parameter shifts and power compression.
Rear Gasket: The woofer has a rear gasket to provide an optimal seal when installing into the enclosure.
Long Excursion: The 10W0v3-4 subwoofer has 11.4mm of linear excursion, giving you louder bass with less distortion.
Enclosure Compatibility
Recommended Sealed Box Volume: JL Audio recommends a 0.65 ft³ sealed box. A diagram is provided in the owner’s manual for a sealed box with external dimensions of 18″ W x 11″ H x 9″ D, assuming 3/4″ thick material. (If you are using 5/8″ thick materials, you should subtract 1/4″ from each dimension.)
Recommended Ported Box Volume: JL Audio recommends a 1.125 ft³ ported box. A diagram is provided in the owner’s manual for a ported box with external dimensions of 23″ W x 12″ H x 13.625″ D, assuming 3/4″ thick material. (If you are using 5/8″ thick materials, you should subtract 1/4″ from each dimension.) A slot port measuring 10.5″ tall x 1.25″ wide x 32″ long is recommended, resulting in a tuning frequency of 30 Hz and a -3 dB point of 29.6 Hz.
