Rockford Fosgate R1T-S Prime Series Mylar balanced dome tweeters
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
$44.99
-
Pick up from the Woodmart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year
-
Free 30-Day returns
Payment Methods:
Description
Put Rockford Fosgate sound in your car without breaking the bank. Whether you’re customizing your existing system or replacing some burned-out tweeters, Prime tweeters offer clean, crisp performance that’ll keep you and your friends entertained as you drive.
The Prime R1T-S tweeters feature Mylar balanced dome construction that ensures wide dispersion and clear soundstage details. Install a set in your vehicle, and you’ll enjoy vibrant highs that add excitement to your music without grating on your ears. Built-in high-pass filters ensure a smooth audio response, so these tweeters will reproduce your highs faithfully.
Installation note: You’ll need a pair of our universal backstraps to install these tweeters in the factory locations.
Product highlights:
- Mylar balanced dome tweeters (pair)
- flush- and surface-mount hardware included
- 4.5kHz, 6 dB/oct passive crossovers built-in
- power handling: 2-40 watts RMS (80 watts peak power)
- frequency response: 2,500-22,000 Hz
- sensitivity: 72.5 dB
- top-mount depth: 3/4″
- grilles included
- warranty: 1 year
- MFR # R1T-S
- Item # 575R1TS
What’s in the box:
Rockford Fosgate R1T-S owner’s manual
If you need assistance accessing this owner’s manual, please give us a call.
- 2 Tweeters
- 2 Flush mounting brackets (installed)
- 2 Flush mount retaining rings
- 2 Surface mounting brackets
- Four 5/8″ Flat head screws
- Installation and Operation instructions (English/ French/ Spanish/ German/ Italian)
Features & specs
| General | ||
|---|---|---|
| Speaker Size | 1/2 | |
| Driver Design | 1-way | |
| Woofer Design | — | |
| Woofer Material | — | |
| Woofer Surround | — | |
| Midrange Design | — | |
| Midrange Material | — | |
| Tweeter Design | Balanced Dome | |
| Tweeter Material | Mylar | |
| Super Tweeter Design | — | |
| Super Tweeter Material | — | |
| Impedance (Ohms) | 4 | |
| Weather-resistant | No | |
| Grilles Included | Black steel mesh | |
| Parts Warranty | 1 Year | |
| Labor Warranty | 1 Year | |
| Specifications | ||
| Sensitivity (1W at 1 meter) | 72.5 | |
| Sensitivity at 2.83 volts | 75.5 | |
| Frequency Response | 2500 – 22k Hz | |
| Maximum RMS Wattage | 40 | |
| Peak Power Handling (Watts) | 80 | |
| Top-mount Depth (Inches) | 0 3/4 | |
| Bottom-mount Depth (Inches) | N/A | |
| Cutout Diameter or Length (inches) | 1 7/8 | |
| Mounting Height (Inches) | 0.3125 | |
| Frame Width | 2.125 | |
| Frame Length | 2.125 | |
Product Research
Features
Overview: The Rockford Fosgate Prime R1T-S is a dedicated tweeter system featuring a lightweight Mylar dome. Multiple tweeter mounting configurations allow flush, surface, and angle configurations.
Mylar Dome Tweeter: The Prime R1T-S features a lightweight Mylar dome tweeter for high sensitivity and smooth extended frequency response. This low distortion material allows accurate reproduction of high frequencies for an open sound stage.
Crossover: The R1T-S tweeter has an integrated 6 dB/octave high-pass crossover fixed at 4,500 Hz.
Mounting: The Rockford Fosgate R1T-S provides multiple mounting configurations. You can choose a flush mount, surface mount, or angle mount installation. You can further angle the tweeter once installed in any of the included mounts.
| Tweeter Mounting Dimensions | Flush | Surface | Angle |
|---|---|---|---|
| Mounting Height | 0.3125″ | 1.095″ | 1.875″ |
| Mounting Depth | 0.75″ | 0.6875″ (screw depth) | 0.625″ (screw depth) |
| Frame Diameter | 2.125″ | 1.815″ | 1.815″ |
| Cutout Diameter | 1.835″ | N/A | N/A |
